| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10 Set Per 1 Month |
| Delivery Time | 7-15 Working Days |
| Printhead | On-demand piezo head (Printheads are arranged in four staggered lines) |
| Print resolutions | 300dpi, 600dpi, 900dpi, 1,200dpi |
| Head gap | 4 gap settings (1.7mm / 1.9mm / 2.6mm / 3.3mm） |
| Maximum print width | 3,200 mm (126 in) |
| Maximum media width | 3,250 mm (127.9 in) (When roll holders are used:1,620mm (63.7 in) × 1) (Twin-roll printing with roll holders: 1,524 mm (60 in) × 2) |
| Minimum media width | 210 mm (8.2 in) (Twin-roll printing: 210 mm (8.2 in) × 2) |
| Ink Type/ Color | LUS-120 (C, M, Y, K, Lc, Lm, W) |
| Ink Packaging | 1L ink bottle Each ink color can be filled up to 3 liters in the ink supply unit. |
| Media thickness | 1.0 mm or less |
| Roll outer diameter | Large drive shaft: Φ250 mm (9.8 in) or less Roll holder: Φ180mm (7 in) or less |
| Roll weight | Large drive shaft: 100kg (220.5 lb) or less Roll holder: 18kg (39.7 lb) or less |
| Interface | Ethernet 1000BASE-T / USB2.0 |
| Power supply | AC200 - 240V±10％ 50/60Hz ±1Hz 18A or less |
| Power consumption | 4.3kW or less |
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65 %Rh (No condensing) |
| Dimensions (W×D×H) | 5,680 mm × 1,220 mm × 1,440 mm (223.6 in × 48 in × 56.7 in) (Dimensions of the ink supply unit is included.) |
| Weight | 910kg (2,006 lb) (Weight of the ink supply unit is included.) |
| Packaging Details | Standard Packaging |
| product name | UV Roll to Roll Printer |
| feature | High precision,High Production |
| brand | MIMAKI |
| Technology | Advanced UV-LED |
| Design | Eco-Friendly |
| Brand Name | JOYINJET |
| Model Number | UJV55-320 |
| Certification | CE |
| Place of Origin | CHINA |
View Detail Information
Explore similar products
900dpi 1200dpi Mimaki UCJV300-160 LED UV Inkjet Printer Cutter
4 Layer / 5 Layer Mimaki UCJV300-75 Roll To Roll UV Printing Machine
1090mm 300dpi Mimaki UCJV300-107 LED UV Inkjet Printer And Cutter
128 Inch 3.2m UV Roll Fed Printer 1200DPI Multicolor MIMAKI UJV55-320
Product Specification
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability | 10 Set Per 1 Month |
| Delivery Time | 7-15 Working Days | Printhead | On-demand piezo head (Printheads are arranged in four staggered lines) |
| Print resolutions | 300dpi, 600dpi, 900dpi, 1,200dpi | Head gap | 4 gap settings (1.7mm / 1.9mm / 2.6mm / 3.3mm） |
| Maximum print width | 3,200 mm (126 in) | Maximum media width | 3,250 mm (127.9 in) (When roll holders are used:1,620mm (63.7 in) × 1) (Twin-roll printing with roll holders: 1,524 mm (60 in) × 2) |
| Minimum media width | 210 mm (8.2 in) (Twin-roll printing: 210 mm (8.2 in) × 2) | Ink Type/ Color | LUS-120 (C, M, Y, K, Lc, Lm, W) |
| Ink Packaging | 1L ink bottle Each ink color can be filled up to 3 liters in the ink supply unit. | Media thickness | 1.0 mm or less |
| Roll outer diameter | Large drive shaft: Φ250 mm (9.8 in) or less Roll holder: Φ180mm (7 in) or less | Roll weight | Large drive shaft: 100kg (220.5 lb) or less Roll holder: 18kg (39.7 lb) or less |
| Interface | Ethernet 1000BASE-T / USB2.0 | Power supply | AC200 - 240V±10％ 50/60Hz ±1Hz 18A or less |
| Power consumption | 4.3kW or less | Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65 %Rh (No condensing) |
| Dimensions (W×D×H) | 5,680 mm × 1,220 mm × 1,440 mm (223.6 in × 48 in × 56.7 in) (Dimensions of the ink supply unit is included.) | Weight | 910kg (2,006 lb) (Weight of the ink supply unit is included.) |
| Packaging Details | Standard Packaging | product name | UV Roll to Roll Printer |
| feature | High precision,High Production | brand | MIMAKI |
| Technology | Advanced UV-LED | Design | Eco-Friendly |
| Brand Name | JOYINJET | Model Number | UJV55-320 |
| Certification | CE | Place of Origin | CHINA |
| High Light | 3.2M Large Format UV Printer ，Mimaki UJV55-320 ，UJV55-320 LED UV Inkjet Printer | ||
The UJV55-320, 3.2 m-wide LED-UV inkjet printer, offers high cost performance and expands your business.
| UJV55-320 | ||
|---|---|---|
| Printhead | On-demand piezo head (Printheads are arranged in four staggered lines) | |
| Print resolutions | 300dpi, 600dpi, 900dpi, 1,200dpi | |
| Head gap | 4 gap settings (1.7mm / 1.9mm / 2.6mm / 3.3mm) | |
| Maximum print width | 3,200 mm (126 in) | |
| Maximum media width | 3,250 mm (127.9 in) (When roll holders are used:1,620mm (63.7 in) × 1) (Twin-roll printing with roll holders: 1,524 mm (60 in) × 2) | |
| Minimum media width | 210 mm (8.2 in) (Twin-roll printing: 210 mm (8.2 in) × 2) | |
| Ink | Type/ Color | LUS-120 (C, M, Y, K, Lc, Lm, W) |
| Packaging | 1L ink bottle Each ink color can be filled up to 3 liters in the ink supply unit. | |
| Media thickness | 1.0 mm or less | |
| Roll outer diameter | Large drive shaft: Φ250 mm (9.8 in) or less Roll holder: Φ180mm (7 in) or less | |
| Roll weight | Large drive shaft: 100kg (220.5 lb) or less Roll holder: 18kg (39.7 lb) or less | |
| Interface | Ethernet 1000BASE-T / USB2.0 | |
| Power supply | AC200 - 240V±10％ 50/60Hz ±1Hz 18A or less | |
| Power consumption | 4.3kW or less | |
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65 %Rh (No condensing) | |
| Dimensions (W×D×H) | 5,410 mm × 995 mm × 1,440 mm (213 in × 39.2 in × 56.7 in) (Dimensions of the ink supply unit is excluded.) | |
| 5,680 mm × 1,220 mm × 1,440 mm (223.6 in × 48 in × 56.7 in) (Dimensions of the ink supply unit is included.) | ||
| Weight | 910kg (2,006 lb) (Weight of the ink supply unit is included.) | |
| LUS-120 ［C,M,Y,K,Lc,Lm,W］ | C M Y K |
|---|---|
| C M Y K Lc Lm W |
*Click to view larger image.
 |  |  |  | |||
| Illumination signboard | Outdoor signboard | Poster | Banner |
