| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10 Set Per 1 Month |
| Delivery Time | 7-15 Working Days |
| Print head | On-demand piezo print head |
| Print resolution | 600dpi, 900dpi, 1200dpi |
| Print gap | By manual 2 levels (1.5/2.0 mm) |
| Ink Type/Color | Eco-solvent ink SS22 (C,M,Y,K,Lc,Lm,Lk,Or) SS21 (C,M,Y,K,Lc,Lm,Lk,Or) BS4 (C,M,Y,K) *1 |
| Ink Capacity *2 | SS22：440ml Ink cartridge / 1L Ink pack SS21: 440ml Ink cartridge / 2L Ink pack BS4: 600ml Ink pack *3 / 2L Ink pack |
| Maximum print width | 1,610mm (63.4") |
| Media Maximum width | 1,620mm (63.8") |
| Media Thickness | 1.0 mm or lower |
| Media Roll diameter | φ180 mm or less |
| Media Roll weight | 25 kg (55.1lb) or less [45 kg (99.2 lb) or less with option *4] |
| Media Roll inside diameter | 2 inch / 3 inch |
| Interface | Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed |
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, Energy Star, RCM, KC |
| Power supply | Single-phase (AC 100–120V/200–240V)×2 50/60Hz±1Hz |
| Power consumption | Max. 1,320 W x 2 or less / Min. 4.5 W or less (Sleep mode) |
| Operational environment | Temperature: 20–30 °C (68–86 °F) Relative humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level |
| Dimensions (W×D×H) | 2,770 x 748 x 1,370 mm (109.0 x 29.4 x 53.9") |
| Weight | 140 kg (308.6 lb) |
| Packaging Details | Standard Packaging |
| feature | High precision |
| product name | Eco Solvent Printer |
| ink type | Eco-solvent ink / Sublimation ink |
| type | entry model |
| Place of Origin | Japan |
| Brand Name | MIMAKI |
| Certification | CE |
View Detail Information
Explore similar products
MIMAKI JV330-160 Eco Solvent Ink Printer 2L Ink Pack 1610mm Width
800mm Width Inkjet Printer And Cutter 1080dpi 1440dpi Mimaki CJV150-75
1090mm Inkjet Printer Cutter 360dpi-1440dpi Mimaki CJV150-107 With Silver Ink
540dpi 720dpi Eco Solvent Printer And Cutter Mimaki CJV150-130
Product Specification
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability | 10 Set Per 1 Month |
| Delivery Time | 7-15 Working Days | Print head | On-demand piezo print head |
| Print resolution | 600dpi, 900dpi, 1200dpi | Print gap | By manual 2 levels (1.5/2.0 mm) |
| Ink Type/Color | Eco-solvent ink SS22 (C,M,Y,K,Lc,Lm,Lk,Or) SS21 (C,M,Y,K,Lc,Lm,Lk,Or) BS4 (C,M,Y,K) *1 | Ink Capacity *2 | SS22：440ml Ink cartridge / 1L Ink pack SS21: 440ml Ink cartridge / 2L Ink pack BS4: 600ml Ink pack *3 / 2L Ink pack |
| Maximum print width | 1,610mm (63.4") | Media Maximum width | 1,620mm (63.8") |
| Media Thickness | 1.0 mm or lower | Media Roll diameter | φ180 mm or less |
| Media Roll weight | 25 kg (55.1lb) or less [45 kg (99.2 lb) or less with option *4] | Media Roll inside diameter | 2 inch / 3 inch |
| Interface | Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed | Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, Energy Star, RCM, KC |
| Power supply | Single-phase (AC 100–120V/200–240V)×2 50/60Hz±1Hz | Power consumption | Max. 1,320 W x 2 or less / Min. 4.5 W or less (Sleep mode) |
| Operational environment | Temperature: 20–30 °C (68–86 °F) Relative humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level | Dimensions (W×D×H) | 2,770 x 748 x 1,370 mm (109.0 x 29.4 x 53.9") |
| Weight | 140 kg (308.6 lb) | Packaging Details | Standard Packaging |
| feature | High precision | product name | Eco Solvent Printer |
| ink type | Eco-solvent ink / Sublimation ink | type | entry model |
| Place of Origin | Japan | Brand Name | MIMAKI |
| Certification | CE | ||
| High Light | JV200-160 Eco Solvent Printer ，Eco Solvent Printer 600dpi ，1200dpi Roll To Roll Inkjet Printer | ||
"JV200 Series" is a Roll to Roll eco-solvent inkjet printer which equipped with a single print head of "330 Engine" in our flag-ship printer, enabling even inexperienced operators to produce printed products beautifully, quickly, and easily.
Beautiful printing. Mimaki's flag-ship printer's "330 Engine" a single print head is mounted to achieve high image quality.
Reliable even during busy periods. Highest practical print speed at entry level: 17.0 m²/h
Simple design that is easy for anyone to use. Easy to work with, easy to check, and easy to maintain.
Compatible with our new ink "SS22," which reduces odor by approximately 40%*1 and does not contain GBL*2, the use of which has been increasingly regulated around the world in recent years. The industry-leading outdoor weather resistance keeps printed materials vividly colored, while taking operators and the global environment into consideration.
The JV200 is equipped with a single print head of "330 Engine" in Mimaki's flagship printer. The technology of precise control of a minimum 3pl ink drop and the print head that delivers high-density prints, even at high speeds, resulting in overwhelmingly beautiful printing.
Single print head system contributes less cleaning time and adjustment time. The simple design allows you to work quickly and easily.
Automatically performs necessary adjustment at the media setup to ensure optimal image quality at all times.
(DAS | Dot Adjustment System)
Anyone can easily reduce ink consumption without technical expertise.
This function is available with any substrates and profiles.
Simple Create is software that allows you to create labels, POP, stickers, and other designs without a need of DTP software.
It provides simple tools for creating designs and cutlines, as well as direct output from the software.
| JV200-130 | JV200-160 | ||
|---|---|---|---|
| Print head | On-demand piezo print head | ||
| Print resolution | 600dpi, 900dpi, 1200dpi | ||
| Print gap | By manual 2 levels (1.5/2.0 mm) | ||
| Ink | Type/Color | Eco-solvent ink SS22 (C,M,Y,K,Lc,Lm,Lk,Or) SS21 (C,M,Y,K,Lc,Lm,Lk,Or) BS4 (C,M,Y,K) *1 | |
| Capacity *2 | SS22:440ml Ink cartridge / 1L Ink pack SS21: 440ml Ink cartridge / 2L Ink pack BS4: 600ml Ink pack *3 / 2L Ink pack | ||
| Maximum print width | 1,361mm (53.6") | 1,610mm (63.4") | |
| Media | Maximum width | 1,371mm (54.0") | 1,620mm (63.8") |
| Thickness | 1.0 mm or lower | ||
| Roll diameter | φ180 mm or less | ||
| Roll weight | 25 kg (55.1lb) or less [45 kg (99.2 lb) or less with option *4] | ||
| Roll inside diameter | 2 inch / 3 inch | ||
| Interface | Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed | ||
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, Energy Star, RCM, KC | ||
| Power supply | Single-phase (AC 100–120V/200–240V)×2 50/60Hz±1Hz | ||
| Power consumption | Max. 1,320 W x 2 or less / Min. 4.5 W or less (Sleep mode) | ||
| Operational environment | Temperature: 20–30 °C (68–86 °F) Relative humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level | ||
| Dimensions (W×D×H) | 2,520 x 748 x 1,370 mm (99.2 x 29.4 x 53.9") | 2,770 x 748 x 1,370 mm (109.0 x 29.4 x 53.9") | |
| Weight | 130 kg (286.6 lb) | 140 kg (308.6 lb) | |
*Click to view larger image.
 |  |  |  | |||
| Outdoor signboard | Poster | Illumination signboard | Banner |
