China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine

  1. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
  2. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
  3. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
  4. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
  5. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
  6. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine
  7. China LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine

LC-PM1-250R Semi-Automatic Single Color Roller Pad Printing Machine

  1. MOQ： 1set
  2. Price： US $ 7100 / set
  3. Get Latest Price
Printing color number 1 colors
Maximum printing speed 800pcs/hr
Payment Terms T/T,D/P,D/A,L/C
Packaging Details WOODEN CASE
Up and down stroke 0-200mm
Delivery Time 35days
Steel plate size 160*583mm*0.5mm
Power supply 220V 50Hz
Model LC-PM1-250R
Ink cup size 140mm
Front to back path 0-400mm
Model Number LC-PM1-250R
Place of Origin China
Certification CE
Brand Name LC

View Detail Information

Inquiry by Email Get Latest Price
Chat online Now Ask for best deal

Explore similar products

  1. China LC Automatic 6 Color PLC Control Rotary Tampo Pad Printer Machine with Servo

    LC Automatic 6 Color PLC Control Rotary Tampo Pad Printer Machine with Servo

    Chat online Now
  2. China 4 color large size shuttle pad printer

    4 color large size shuttle pad printer

    Chat online Now
  3. China Double head Independent cylinder 2 color pad printing machine for toys pen pad

    Double head Independent cylinder 2 color pad printing machine for toys pen pad

    Chat online Now
  4. China Single colour automatic feeding unloading cleaning rubber oil cup pad printer

    Single colour automatic feeding unloading cleaning rubber oil cup pad printer

    Chat online Now
  1. Product Details
  2. Company Details

Product Specification

Printing color number 1 colors Maximum printing speed 800pcs/hr
Payment Terms T/T,D/P,D/A,L/C Packaging Details WOODEN CASE
Up and down stroke 0-200mm Delivery Time 35days
Steel plate size 160*583mm*0.5mm Power supply 220V 50Hz
Model LC-PM1-250R Ink cup size 140mm
Front to back path 0-400mm Model Number LC-PM1-250R
Place of Origin China Certification CE
Brand Name LC

Product Description

one color roller pad printing machine LC-PM1-250R

Operation mode: semi-automatic
Printing color number: 1 colors
Print heads: 1
Steel plate size 160*583mm*0.5mm
Ink cup size 140mm
Maximum printing speed 800pcs/hr
Up and down stroke 0-200mm
Front to back path 0-400mm
Table area: 650*165mm
Workstation: 1Pcs
Power supply: 220V 50Hz
Air pressure: 6 Bar

Application Area
This single-color roller pad printing machine is specifically designed for printing on elongated and cylindrical products. It is widely used for applying logos, batch numbers, expiration dates, barcodes, and simple patterns on items such as:

  • Bottles, cans, and cups
  • Cylindrical packaging and containers
  • Pens, tubes, and similar long-shaped products

Product Advantages

  • Optimized for Long & Cylindrical Products: Features an extended steel plate size (160*583mm) and a long front-to-back stroke (0-400mm), making it ideal for printing on tall or elongated items.
  • High Precision & Stability: The semi-automatic operation mode combined with a stable 6 Bar air pressure system ensures consistent printing quality and accurate positioning.
  • Efficient Production: Capable of reaching a maximum printing speed of 800pcs/hr, providing a good balance between speed and quality for medium-volume production runs.
  • Versatile Printing Stroke: The adjustable up-and-down stroke (0-200mm) accommodates products of varying heights, enhancing the machine's flexibility.
  • Closed Ink Cup System: The 140mm ink cup design minimizes solvent evaporation, reduces ink waste, and maintains a cleaner working environment.
  • User-Friendly Operation: Simple semi-automatic control makes it easy to operate and maintain, reducing the learning curve for operators.

Product Image
